Forward tipping box rotator for telehandlers
K75 voorover kantelaar | forward tipping box rotator
Forward tipping box rotator for telehandlers
- 110° tipping angle + vehicle tilt angle
- Only suitable for telescopic forklift (because of tilting space)
- Clamps exactly on the box edge (for 1600 and 1800 mm wide boxes)
- Suitable for all marks of telehandlers
- No rotation elements next to the box
- Suitable for boxes with or without bottom deck
- Box depth adjustable between 850 - 1250 mm
- Box height adjustable between 800 - 1250 mm
- Complete with hydraulic hoses and quick connectors
- Standard equipped with sequence valve (2 hose connection)
Properties
Are you interested in this product or do you want a demonstration?
K75A:
■ Suitable for box widths between 1200 - 1800 mm
■ Two fixed forks as standard (790 mm centers)
■ 1 clamping cilinder
■ Suitable for box widths between 1200 - 1800 mm
■ Two fixed forks as standard (790 mm centers)
■ 1 clamping cilinder
K75B:
■ Suitable for box widths > 1800 mm
■ With FEM2 fork carriage (1460 mm) and two adjustable forks
■ 2 clamping cilinders
■ Suitable for box widths > 1800 mm
■ With FEM2 fork carriage (1460 mm) and two adjustable forks
■ 2 clamping cilinders
Swipe right for all types
Types and specifications
Type
Center of gravity
Weight
Maximum load
Frontal extension length
Roll-over upper clamp for boxes > 1200 mm
With four instead of two forks (for box width 2400 mm)
Attachment parts for telescopic forklift
K75A
K75B
500 mm
531 mm
615 kg
840 kg
1750 kg
2750 kg
500 mm
570 mm
€ 525,–
Retail price excl. VAT
€ 525,–
Retail price excl. VAT
€ 2.000,–
Retail price excl. VAT
€ 2.000,–
Retail price excl. VAT
SPECIALIST IN BOX TIPPERS
As a specialist, WIFO offers an extensive range of box tippers. Our tippers are extremely suitable for picking up, transporting and emptying any type of box and the most diverse agricultural products such as potatoes, onions, carrots but also products in the processing industry such as recycled products.
